Specifications

Interface Type

PCI-E

Input Type

DB15 x 2 (Video), DB9 x 2 (Audio)

Video Input(s)

8, 16 Cams

Audio Input(s)

8, 16 Channels

TV Output

RCA Connector x 1

Total Recording Rate

CIF

240 fps (NTSC), 200 fps (PAL)

D1

120 fps (NTSC), 100 fps (PAL)

Turbo VGA

240 fps (NTSC), 200 fps (PAL)

Turbo D1

240 fps (NTSC), 200 fps (PAL)

Display Rate

CIF

480 fps (NTSC), 400 fps (PAL)

D1

480 fps (NTSC), 400 fps (PAL)

Video Resolution

NTSC

720x480, 720x480 De-interlace, 640x480,
640x480 De-interlace, 360x240, 320x240

PAL

720x576, 720x576 De-interlace, 640x480,
640x480 De-interlace, 360x288, 320x240

Compression Format

Geo MPEG4, Geo MPEG4 (ASP), Geo H264, Geo H264 V2

GV-Multi Quad Card Support

Yes

GV-Loop Through Card Support

Yes

GV-NET/IO Card Support

Yes

Dimensions (W x H)

187.7 x 117.1 (mm) / 7.38 x 4.61 (in)

Installation Guide

Single Card
Two Cards

Note: GV-1240A is currently not compatible with VIA series and ATI series chipset motherboards, and 64-bit Windows operating system.

Minimum System Requirements For One Card

OS Supported

Windows 2000 / Windows XP / Windows Server 2003 / Windows Vista (Not support 64-bit version of Windows)

CPU

Pentium 4-3.0 GHz Dual Core

RAM

Windows 2000 / XP: 2 x 512 MB Dual Channels
Windows Vista / Server 2003: 2 x 1 GB Dual Channels

HDD

120 GB

VGA

ATI Radeon X1300 PCI-E /
NVIDIA GeForce 7300 PCI-E

DirectX

9.0c

Minimum System Requirements For Two Cards

OS Supported

Windows 2000 / Windows XP / Windows Server 2003 / Windows Vista (Not support 64-bit version of Windows)

CPU

Core 2 Duo, 2.53 GHz

RAM

2 x 1 GB Dual Channels

HDD

250 GB

VGA

ATI Radeon X1300 PCI-E /
NVIDIA GeForce 7300 PCI-E

DirectX

9.0c

Minimum System Requirements For Turbo Mode

Model

GV-1240A x 1

GV-1240A x 2

CPU

Core 2 Duo, 3.0 GHz

Core 2 Quad, 2.8 GHz

RAM

2 x 512 MB Dual Channels (Windows 2000 / XP)
2 x 1 GB Dual Channels
(Windows Server 2003 / Vista)

2 x 1 GB Dual Channels

VGA

ATI Radeon X1300 PCI-E /
NVIDIA n7300 PCI-E

ATI Radeon X1300 PCI-E / NVIDIA GeForce 7300 PCI-E

HDD

160 GB

320 GB
