Specifications
|
Interface
Type
|
PCI-E
|
Input
Type
|
DB15
x 2 (Video), DB9 x 2 (Audio)
|
Video
Input(s)
|
8,
12, 16 Cams
|
Audio
Input(s)
|
8,
12, 16 Channels
|
TV
Output
|
RCA
Connector x 1
|
Total
Recording Rate
|
CIF
|
120
fps (NTSC), 100 fps (PAL)
|
D1
|
80
fps (NTSC), 72 fps (PAL)
|
Turbo
VGA
|
120
fps (NTSC), 100 fps (PAL)
|
Turbo
D1
|
120
fps (NTSC), 100 fps (PAL)
|
Display
Rate
|
CIF
|
480
fps (NTSC), 400 fps (PAL)
|
D1
|
480
fps (NTSC), 400 fps (PAL)
|
Video
Resolution
|
NTSC
|
720x480,
720x480 De-interlace, 640x480,
640x480 De-interlace, 360x240, 320x240
|
PAL
|
720x576,
720x576 De-interlace, 640x480,
640x480 De-interlace, 360x288, 320x240
|
Compression
Format
|
Geo
MPEG4, Geo MPEG4 (ASP), Geo H264, Geo H264 V2
|
GV-Multi
Quad Card Support
|
Yes
|
GV-Loop
Through Card Support
|
Yes
|
GV-NET/IO
Card Support
|
Yes
|
Dimensions
(W x H)
|
187.7
x 117.1 (mm) / 7.38 x 4.61 (in)
|
Installation
Guide
|
Single
Card
Two
Cards
|
Note:
GV-1120A is currently not compatible
with VIA series and ATI series chipset
motherboards, and 64-bit Windows operating
system.
|
Minimum
System Requirements For One Card
|
OS
Supported
|
Windows
2000 / Windows XP / Windows Server 2003 /
Windows Vista (Not support 64-bit version of
Windows)
|
CPU
|
Pentium
4-3.0 GHz with Hyper-Threading
|
RAM
|
Windows
2000 / XP: 2 x 512 MB Dual Channels
Windows Vista / Server 2003: 2 x 1 GB Dual
Channels
|
HDD
|
80
GB
|
VGA
|
ATI
Radeon X1300 PCI-E /
NVIDIA GeForce 7300 PCI-E
|
DirectX
|
9.0c
|
Minimum
System Requirements For Two Cards
|
OS
Supported
|
Windows
2000 / Windows XP / Windows Server 2003 /
Windows Vista (Not support 64-bit version of
Windows)
|
CPU
|
Pentium
4- 3.0 GHz, Dual Core
|
RAM
|
2
x 1 GB Dual Channels
|
HDD
|
160
GB
|
VGA
|
ATI
Radeon X1300 PCI-E /
NVIDIA GeForce 7300 PCI-E
|
DirectX
|
9.0c
|
Minimum
System Requirements For Turbo Mode
|
Model
|
GV-1120A
x 1
|
GV-1120A
x 2 |
CPU
|
Pentium
4, 3.0 GHz, Dual Core
|
Core
2 Quad, 2.4 GHz
|
RAM
|
2
x 512 MB Dual Channels (Windows 2000 / XP)
2 x 1 GB Dual Channels
(Windows Server 2003 / Vista)
|
2
x 1 GB Dual Channels
|
VGA
|
ATI
Radeon X1300 PCI-E /
NVIDIA n7300 PCI-E
|
ATI
Radeon X1300 PCI-E / NVIDIA GeForce 7300 PCI-E
|
HDD
|
120
GB
|
250
GB |
